DBA 00-05 Mitsubishi Evo V/VI/VII/VIII / 06-08 Evo IX Front Drilled & Slotted 5000 Series Brembo Onl
€291.55 incl. 19% VAT plus shipping costs
Limited availability, delivery time on request
Questions about the product? Write us!
Article no.:
52218.1XS
Why Streetstylez?
- Over 20 years of experience in parts import
- 100% genuine brand products – no replicas
- Sales and shipping from Germany – no duties, no hidden fees within EU
Description
DBA 00-05 Mitsubishi Evo V/VI/VII/VIII / 06-08 Evo IX Front Drilled & Slotted 5000 Series Brembo Only
Upgrade your brake performance with DBA's 5000 Series drilled and slotted front rotor, specifically designed for Mitsubishi Evo V/VI/VII/VIII and 06-08 Evo IX models. This high-performance rotor is a direct replacement for your Brembo brakes.
| Diameter [mm] | 320| |
| Thickness [mm] | 32| |
| Disc Vent | Kangaroo Paw| |
| Annulus [mm] (Maximum useable pad width) | 64| |
| Pitch Circle Diameter (P.C.D.) | 175| |
| Inside Diameter [mm] | 192| |
| Diameter & Number of Bolt Holes [mm] | 6.4 (x12)| |
| Air Gap [mm] | 14| |
| Offset [mm] | -6,35| |
| Flange Inside Diameter [mm] | 161| |
| Flange Thickness [mm] | 6,35| |
| Hole Type | Round Hole| |
| Stage | Stage 5| |
| Tech Bulletins | Bedding in Brakes| |
| Tech Bulletins | How to clean a Disc Rotor before fitting| |
| Tech Bulletins | Motorsport - Important Info| |
| Replacement Nuts | Included |
Vehicle Compatibility
Manufacturer:
DBA manufactures brake rotors for the automotive performance market. Their products include slotted and/or drilled rotors for both street and race applications. DBA’s unique “kangaroo paw” vented design utilizes teardrop patterned pillars, which increases cooling efficiency up to 20% over traditional vented rotors. DBA rotors also feature thermo-graphic paint markings that indicate the temperature of the rotor at specified thresholds, allowing the user to check brake performance quickly and easily.
