DBA 10 Stud Hole Rear Drilled & Slotted 4000 Series Rotor for 01-07 Subaru WRX/STI

Manufacturer: DBA

Article no.: 4655XS-10

€229.67*

Questions about the product? Write us!

Available from supplier. Delivery time: 4–5 business days (EU: +3 days)

incl. 19% VAT plus shipping costs

DBA 01-07 Subaru WRX/STI 10 Stud Hole Rear Drilled & Slotted 4000 Series Rotor

Upgrade your Subaru WRX/STI's braking performance with DBA's 4000 Series XS rotors. Cast from high-carbon alloyed iron and undergoing Thermal Stability Profiling, these rotors are designed to handle intense braking applications with ease.

Patented Kangaroo Paw ventilation for increased surface area and improved cooling efficiency
Direct replacement suitability for easy installation
CBN-machined turned for reduced Disc Thickness Variation and parallelism
Moisture-proof corrosion protection packaging

DBA's 4000 Series XS rotors feature the best technology and materials for maximum performance. With a unique drill and slot pattern, these rotors make the perfect direct replacement for your Subaru WRX/STI.

Diameter [mm]	316
Disc Vent	Kangaroo Paw
Number of Holes	10
Inner Diameter [mm]	58
Minimum Thickness [mm]	18
Thickness [mm]	20
Height [mm]	67.5
Stage	Stage 3
Tech Bulletins	Bedding in Brakes
Tech Bulletins	How to clean a Disc Rotor before fitting
Tech Bulletins	Motorsport - Important Info

Make	Model	Year	Type
Subaru	Impreza	2004	WRX STI
Subaru	Impreza	2005	WRX STI
Subaru	Impreza	2006	WRX STI
Subaru	Impreza	2007	WRX STI
Subaru	Impreza	2007	WRX STI Limited

DBA manufactures brake rotors for the automotive performance market. Their products include slotted and/or drilled rotors for both street and race applications. DBA’s unique “kangaroo paw” vented design utilizes teardrop patterned pillars, which increases cooling efficiency up to 20% over traditional vented rotors. DBA rotors also feature thermo-graphic paint markings that indicate the temperature of the rotor at specified thresholds, allowing the user to check brake performance quickly and easily.
