DBA Rear T3 Slotted 4000 Series Rotor for 14-21 Subaru WRX / 12-21 Scion FR-S/Toyota GR 86

Manufacturer: DBA

Article no.: 42659S-10

€165.41*

Available from the supplier, delivery time: 4-5 working days

DBA 14-21 Subaru WRX / 12-21 Scion FR-S/Toyota GR 86 Rear T3 Slotted 4000 Series Rotor

Experience the ultimate in braking performance with DBA's 4000 Series T3 rotors. Built on the foundations of DBA's T2 slot, the T3 slot design features additional, precise, CNC machined tri-symmetrical slots, resulting in an even quieter, more responsive and smoother brake pedal feel.

Tri-symmetrical slot design for improved brake pedal feel
XG-150 High Carbon Alloyed Iron for increased strength and durability
Thermal Stability Profiling (TSP) for improved heat dissipation
Thermo-graphic paint markings (THGP) for accurate temperature monitoring
Direct replacement suitability for easy installation
Moisture proof corrosion protection packaging for extended lifespan

Diameter [mm]	286
Disc Vent	Solid
Number of Holes	10
Inner Diameter [mm]	58
Minimum Thickness [mm]	8,5
Thickness [mm]	10
Height [mm]	63.5
Pitch Circle [mm]	100 & 114.3
Stage	Stage 4
Tech Bulletins	Bedding in Brakes
Tech Bulletins	How to clean a Disc Rotor before fitting
Tech Bulletins	Motorsport - Important Info

Make	Model	Year	Type
Subaru	Forester	2009	X
Subaru	Forester	2009	X Limited
Subaru	Forester	2009	X Premium
Subaru	Forester	2009	XT
Subaru	Forester	2009	XT Limited
Subaru	Forester	2010	X
Subaru	Forester	2010	X Limited
Subaru	Forester	2010	X Premium
Subaru	Forester	2010	XT Limited
Subaru	Forester	2010	XT Premium
Subaru	Forester	2011	X
Subaru	Forester	2011	X Limited
Subaru	Forester	2011	X Premium
Subaru	Forester	2011	X Touring
Subaru	Forester	2011	XT Premium
Subaru	Forester	2011	XT Touring
Subaru	Forester	2012	X
Subaru	Forester	2012	X Limited
Subaru	Forester	2012	X Premium
Subaru	Forester	2012	X Touring
Subaru	Forester	2012	XT Premium
Subaru	Forester	2012	XT Touring
Subaru	Forester	2013	X
Subaru	Forester	2013	X Limited
Subaru	Forester	2013	X Premium
Subaru	Forester	2013	X Touring
Subaru	Forester	2013	XT Premium
Subaru	Forester	2013	XT Touring
Subaru	Impreza	2008	2.5i
Subaru	Impreza	2008	Outback Sport
Subaru	Impreza	2008	WRX
Subaru	Impreza	2008	WRX STI
Subaru	Impreza	2009	WRX
Subaru	Impreza	2009	WRX Premium
Subaru	Impreza	2010	WRX
Subaru	Impreza	2010	WRX Limited
Subaru	Impreza	2010	WRX Premium
Subaru	Impreza	2011	WRX
Subaru	Impreza	2011	WRX Limited
Subaru	Impreza	2011	WRX Premium
Subaru	Impreza	2012	WRX
Subaru	Impreza	2012	WRX Limited
Subaru	Impreza	2012	WRX Premium
Subaru	Impreza	2013	WRX
Subaru	Impreza	2013	WRX Limited
Subaru	Impreza	2013	WRX Premium
Subaru	Impreza	2014	WRX
Subaru	Impreza	2014	WRX Limited
Subaru	Impreza	2014	WRX Premium
Subaru	Legacy	2008	2.5i
Subaru	Legacy	2008	2.5i Limited
Subaru	Legacy	2008	2.5i Special Edition
Subaru	Legacy	2009	2.5i
Subaru	Legacy	2009	2.5i Limited
Subaru	Legacy	2009	2.5i Special Edition
Subaru	Legacy	2010	2.5GT
Subaru	Legacy	2010	2.5i
Subaru	Legacy	2010	2.5i Limited
Subaru	Legacy	2010	2.5i Premium
Subaru	Legacy	2011	2.5GT
Subaru	Legacy	2011	2.5i
Subaru	Legacy	2011	2.5i Limited
Subaru	Legacy	2011	2.5i Premium
Subaru	Outback	2010	2.5i
Subaru	Outback	2010	2.5i Limited
Subaru	Outback	2010	2.5i Premium
Subaru	Outback	2011	2.5i
Subaru	Outback	2011	2.5i Limited
Subaru	Outback	2011	2.5i Premium
Subaru	Outback	2012	2.5i
Subaru	Outback	2012	2.5i Limited
Subaru	Outback	2012	2.5i Premium
Subaru	Outback	2013	2.5i
Subaru	Outback	2013	2.5i Limited
Subaru	Outback	2013	2.5i Premium
Subaru	WRX	2015	Base
Subaru	WRX	2015	Limited
Subaru	WRX	2016	Base
Subaru	WRX	2016	Limited
Subaru	WRX	2016	Premium
Subaru	WRX	2017	Base
Subaru	WRX	2017	Limited
Subaru	WRX	2017	Premium

DBA manufactures brake rotors for the automotive performance market. Their products include slotted and/or drilled rotors for both street and race applications. DBA’s unique “kangaroo paw” vented design utilizes teardrop patterned pillars, which increases cooling efficiency up to 20% over traditional vented rotors. DBA rotors also feature thermo-graphic paint markings that indicate the temperature of the rotor at specified thresholds, allowing the user to check brake performance quickly and easily.
